VW Tiguan Manuals

Volkswagen Tiguan Service and Repair Manual: Hardener

Two-Part HS Hardener

Definition:

  • Two-Part HS Hardener -LHA 009 041 A3-
  • Two-Part HS Hardener, Short -LHA 021 004 A3-
  • Two-Part HS Hardener, Extra Short -LHA 009 046 A2-
  • Two-Part HS Hardener, Long -LHA 009 047 A3-
  • Two-Part HS Hardener, Extra Long -LHA 009 048 A3-

Product Description

These are high solid hardeners for several HS fillers and clear coats.

Properties:

  • It has a high solid content for economical and environmentally friendly application.
  • The choice of five versions means it can adapt well to all painting conditions and ensure reliable application.

Application Instructions

Processing

Possible base components:

  • Two-Part HS Vario Filler.
  • Two-Part HS Premium Filler.
  • Two-Part HS Mixed Filler.
  • Two-Part HS Wet-in-Wet Filler.
  • Two-Part HS Clear Coat.
  • Two-Part HS Vario Clear Coat.

Area of application

  1. The Two-Part HS Hardener -LHA 009 041 A3- is suitable for all complete and partial painting at normal temperatures.
  2. The Two-Part HS Hardener, Short -LHA 021 004 A3- is suitable for partial painting at low temperatures and low spray booth ventilation volumes.
  3. The Two-Part HS Hardener, Extra Short -LHA 009 046 A2- is suitable for spot repairs and partial painting at low temperatures.
  4. The Two-Part HS Hardener, Long -LHA 009 047 A3- is suitable for all complete and partial painting at high temperatures.
  5. The Two-Part HS Hardener, Long -LHA 009 048 A3- is suitable for all complete and partial painting at very high temperatures and is characterized by its good flow properties.

Mixture ratio:

  • Refer to the technical application instructions for the respective base components

Hardener selection guide

+ + - Optimum

+ - Suitable

- - Partially suitable

- - - Not suitable

Volswagen Tiguan. P00-10024

Hardener selection Two-Part HS Hardener -LHA 009 041 A3- Two-Part HS Hardener, Short -LHA 021 004 A3- Two-Part HS Hardener, Extra Short -LHA 009 046 A2-
Partial or complete painting (large areas) + - - -
Partial painting (minor repairs) + + + + +
High temperatures above +25 ºC (77 ºF) + - - - -
Very high temperatures: +30 ºC to +35 ºC (86º to 95 ºF) - - - - -
Normal temperature +20 ºC to +25 ºC (68º to 77 ºF) + + - - -
Low temperature +15 ºC to +20 ºC (59º to 68 ºF) - + + +
Oven drying + + + +
Air drying + + + + + +



Hardener selection Two-Part HS Hardener, Long -LHA 009 047 A3- Two-Part HS Hardener, Extra Long -LHA 009 048 A3-
Partial or complete painting (large areas) + + + +
Partial painting (minor repairs) + - -
High temperatures above +25 ºC (77 ºF) + + +
Very high temperatures: +30 ºC to +35 ºC (86º to 95 ºF) + + +
Normal temperature +20 ºC to +25 ºC (68º to 77 ºF) + + +
Low temperature +15 ºC to +20 ºC (59º to 68 ºF) - - -
Oven drying + + + +
Air drying + +

Personal Protective Equipment:

  • Note the safety data sheets
  • Wear the personal protective equipment during application

Volswagen Tiguan. P00-10820

Characteristics

  Two-Part HS Hardener, Extra Short -LHA 009 046 A2- All other two-part HS hardeners
Flashpoint: under +21 ºC (69.8 ºF) above +23 ºC (73.4 ºF)

Storage

All two-part HS hardeners have a guaranteed shelf life of 36 months from date of manufacture. Use no later than the date indicated on the label and store in original container at +20 ºC (68 ºF).

Volswagen Tiguan. P00-10050

Storage Conditions

  • Protect against moisture.

Volswagen Tiguan. P00-10052

  • Seal the container airtight immediately after removing the hardener.

Volswagen Tiguan. P00-10049

Two-Part VHS Hardener and Two-Part VHS Performance Hardener

Definition:

  • Two-Part VHS Hardener -LHA 009 051 A2-/-LVM 009 051 A5-
  • Two-Part VHS Hardener, Short -LHA 009 050 A2-
  • Two-Part VHS Hardener, Long -LHA 009 052 A2-/-LHA 009 052 A3-
  • Two-Part VHS Hardener, Extra Long -LHA 009 053 A2-
  • Two-Part VHS Performance Hardener -LVM 009 038 A2-
  • Two-Part VHS Performance Hardener, Long -LVM 009 039 A2-

Product Description

Two-part VHS hardeners and two-part VHS performance hardeners are suitable for use with high solid products.

Properties:

  • It has a high solid content for economical and environmentally friendly application.
  • Due to the variety of VHS and performance hardeners, they can adapt well to all painting conditions and ensure reliable application.

Application Instructions

Processing

Possible base components:

Note

The two-part HS performance filler can only be processed with two-part VHS performance hardener.

  • Two-Part HS Vario Filler.
  • Two-Part HS Premium Filler.
  • Two-Part HS Mixed Filler.
  • Two-Part HS Performance Filler.
  • Two-Part HS Wet-in-Wet Filler.
  • Two-Part HS Top Coat.
  • Two-Part HS Clear Coat.
  • Two-Part HS Vario Clear Coat.
  • Two-Part HS Optimum Plus Clear Coat.
  • Two-Part HS Brilliant Plus Clear Coat.
  • Two-Part HS Performance Clear Coat.

Area of Application

Note

The two-part VHS performance hardeners are only to be used in the two-part HS performance filler.

  1. The Two-Part VHS Hardener -LHA 009 051 A2-/-LVM 009 051 A5- is suitable for all complete and partial painting at normal temperatures.
  2. The Two-Part VHS Hardener, Short -LHA 009 050 A2- is suitable for partial painting and low spray booth ventilation volumes.
  3. The Two-Part VHS Hardener, Long -LHA 009 052 A2-/-LHA 009 052 A3- is suitable for all complete and partial painting at high temperatures.
  4. The Two-Part VHS Hardener, Extra Long -LHA 009 053 A2- is suitable for all complete and partial painting at very high temperatures.
  5. The Two-Part VHS Performance Hardener -LVM 009 038 A2- is suitable for all complete and partial painting at normal temperatures.
  6. The Two-Part VHS Performance Hardener, Long -LVM 009 039 A2- is suitable for all complete and partial painting at very high temperatures.

Mixture ratio:

  • Refer to the technical application instructions for the respective base components

Hardener Selection Guide

+ + - Optimum

+ - Suitable

- - Partially suitable

- - - Not suitable

Volswagen Tiguan. P00-10024

Hardener Selection Two-Part VHS Hardener -LHA 009 051 A2-/-LVM 009 051 A5- Two-Part VHS Hardener, Short -LHA 009 050 A2-
Partial or complete painting (large areas) + - -
Partial painting (minor repairs) + + +
High temperatures above +25 ºC (77 ºF) + - -
Very high temperatures: +30 ºC to +35 ºC (86º to 95 ºF) - - -
Normal temperature +20 ºC to +25 ºC (68º to 77 ºF) + + - -
Low temperature +15 ºC to +20 ºC (59º to 68 ºF) - + +
Oven drying + + +
Air drying + + + +



Hardener Selection Two-Part VHS Hardener, Long -LHA 009 052 A2-/-LHA 009 052 A3- Two-Part VHS Hardener, Extra Long -LHA 009 053 A2-
Partial or complete painting (large areas) + + +
Partial painting (minor repairs) + +
High temperatures above +25 ºC (77 ºF) + + +
Very high temperatures: +30 ºC to +35 ºC (86º to 95 ºF) - + +
Normal temperature +20 ºC to +25 ºC (68º to 77 ºF) + + + +
Low temperature +15 ºC to +20 ºC (59º to 68 ºF) - -
Oven drying + + + +
Air drying + + +



Hardener Selection Two-Part VHS Performance Hardener -LVM 009 038 A2- Two-Part VHS Performance Hardener, Long -LVM 009 039 A2-
Partial or complete painting (large areas) + + +
Partial painting (minor repairs) + +
High temperatures above +25 ºC (77 ºF) + + +
Very high temperatures: +30 ºC to +35 ºC (86º to 95 ºF) - + +
Normal temperature +20 ºC to +25 ºC (68º to 77 ºF) + + + +
Low temperature +15 ºC to +20 ºC (59º to 68 ºF) - -
Oven drying + + + +
Air drying + + +

Personal Protective Equipment:

  • Note the safety data sheets
  • Wear the personal protective equipment during application

Volswagen Tiguan. P00-10820

Characteristics

  All VHS hardeners
Flashpoint: +24 ºC (75.2 ºF)

Storage

The guaranteed shelf life of VHS hardeners is 36 months from date of manufacture. The guaranteed shelf life of VHS performance hardeners is 12 months. Use no later than the date indicated on the label and store in original container at +20 ºC (68 ºF).

Volswagen Tiguan. P00-10050

Storage Conditions

  • Protect against moisture.

Volswagen Tiguan. P00-10052

  • Seal the container airtight immediately after removing the hardener.

Volswagen Tiguan. P00-10049

Two-Part Adhesive Filler Hardener

Definition:

  • Two-Part Adhesive Filler Hardener -LHA 005 000 A2-

Note

The usage and application instructions for the two-part adhesive filler hardener are described in the appropriate base component.

Aqua Premium Hardener

Definition:

  • Aqua Premium Hardener -LVM 045 000 A1-

Note

The usage and application instructions for the two-part adhesive filler hardener are described in the appropriate base component.
